HypaLUME 24/48 V DC

For the toughest operating conditions: The HELLA HypaLUME 24/48 V DC LED Flood Light Heavy Duty work lamp offers a powerful 25,000 lumens of light output and is designed for exceptionally demanding applications, for example in mining and on construction sites, thanks to its heavy duty construction. Current consumption is 260 watts. It is intended for use in 24 V/ 48 V electrical system environments.

Thanks to a special housing seal and the anti-corrosion coating of the aluminium housing, as well as the lens made of the high-tech material Grilamid®, the work lamp is dustproof and waterproof, as well as protected against external influences such as shocks, impacts, vibrations, salt water, chemicals, and UV radiation.

Depending on the variant, the durable LED technology provides homogeneous illumination in the close-range, long-range, or as extra-wide illumination. The light colour, which is similar to daylight, ensures good perception of the surroundings.

Thanks to the integrated electronics, the HypaLUME 24/48 V DC is protected against polarity reversal and overvoltage. The thermal management concept prevents overheating. The work lamp can be mounted upright and pendant.

Product Advantages

  • Specially developed for applications with extremely high light requirements
  • Perfectly suited for the toughest operating conditions
  • Fully sealed and corrosion-protected

Video of the HypaLUME extreme testing

Technical Data

Operating voltage Multi-voltage (21-52 V DC)
Rated voltage 24 V DC/ 48 V DC
Power consumption max. 260 W
Light output 25,000 lm
Light source LED
Colour temperature 5,700 K
Material

Housing: premium aluminium with non-stick coating
Cover lens: impact-resistant and chemical-resistant Grilamid®

Weight max. 13,560 g
Temperature range -40 °C to +50 °C
Protection class IP 6K9K, IP 6K7
EMC protection RCM, FCC
Mounting Upright and pendant
Connection DEUTSCH DT 4 pin connector, 1,800 mm single pluggable sheathed cable is included in delivery

Program Overview

Illumination Part number
Close-range illumination 1GJ 011 872-501
Long-range illumination 1GJ 011 872-511
Extra-wide illumination 1GJ 011 872-521
