RokLUME 155 TP
Robust and attractive: The HELLA RokLUME 155 TP LED work lamp already stands out with its shapely, compact design, and is suited for universal use. The innovative plastic housing contains powerful technology: Four durable, energy-efficient high-power LEDs bring 1,200 lumens to the working area via the specially developed multifaceted reflector, in the close- or long-range depending on the version. Consumption totals just 15 watts.
The RokLUME 155 TP is also available with an amber light colour, in addition to a version with a light colour similar to daylight. Designed for use in poor visibility conditions such as fog and snow, this version prevents glare and stray light. This significantly increases working comfort.
The lightweight plastic housing is exceptionally robust and absolutely corrosion-resistant. The special material and additional cooling fins effectively dissipate the generated heat and prevent overheating.
The ECE-approved work lamp is absolutely dustproof, waterproof, and high-pressure jet cleaner resistant. Upright or pendant surface mounting is possible.
Robust and attractive: The HELLA RokLUME 155 TP LED work lamp already stands out with its shapely, compact design, and is suited for universal use. The innovative plastic housing contains powerful technology: Four durable, energy-efficient high-power LEDs bring 1,200 lumens to the working area via the specially developed multifaceted reflector, in the close- or long-range depending on the version. Consumption totals just 15 watts.
The RokLUME 155 TP is also available with an amber light colour, in addition to a version with a light colour similar to daylight. Designed for use in poor visibility conditions such as fog and snow, this version prevents glare and stray light. This significantly increases working comfort.
The lightweight plastic housing is exceptionally robust and absolutely corrosion-resistant. The special material and additional cooling fins effectively dissipate the generated heat and prevent overheating.
The ECE-approved work lamp is absolutely dustproof, waterproof, and high-pressure jet cleaner resistant. Upright or pendant surface mounting is possible.
Photo of the close-range illumination of the RokLUME 155 TP
Photo of the close-range illumination of the RokLUME 155 TP amber
Dimensional sketch of the RokLUME 155 TP
Technical Data
| Operating voltage | Multi-voltage (9-32 V) |
| Rated voltage | 12 V/ 24 V |
| Power consumption | 15 W |
| Light output | 1,200 lm |
| Light source | LED |
| Colour temperature |
Standard: 5,000 K |
| Material |
Housing: heat conductive plastic |
| Weight | 380 g |
| Temperature range | -40 °C to +50 °C |
| Protection class | IP 6K9K, IP 6K7 |
| EMC protection | ECE-R10, RCM |
| Mounting | Upright and pendant |
| Connection | 200 mm cable with DEUTSCH DT 2 pin connector |
Program Overview
| Illumination | Cover lens | Part number |
|---|---|---|
| Close-range illumination | Clear | 1GA 996 284-051 |
| Amber | 1GA 996 284-071 | |
| Long-range illumination | Clear | 1GA 996 284-061 |
